Progressive Dynamics Power Converter 9100 Series Inteli-Power 30 Amp Part# 19-0252 PD9130V
Power Converter; Inteli-Power ® 9100 Series; Converts 105 To 130 Volt AC To 13.6 Volt DC; 500 Continuous Watts; 30 Amps Maximum Output Part# 19-0252 PD9130V
SKU: 19-0252
Manufacturer part number: PD9130V
UPC/GTIN: 675566913011
Power Converter; Inteli-Power ® 9100 Series; Converts 105 To 130 Volt AC To 13.6 Volt DC; 500 Continuous Watts; 30 Amps Maximum Output; 80 Percent Efficiency; With Reverse Battery/ Thermal Protection; 8.62 Inch Length x 7-1/4 Inch Width x 4-1/2 Inch Height; With Built-In Total Charge Management System Interface
The Progressive Dynamics INTELI-POWER converters are UL listed for the US and Canada. They provide safe, reliable, filtered DC power to all Recreational Vehicle 12-Volt lighting and appliance circuits. The Inteli-Power converter also safely recharges and maintains the RV battery and has a two-year limited warranty. The built in Total Charge Management System (TCMS) connector allows the RV manufacturer, dealer, or customer to easily add the optional Charge Wizard. The Charge Wizard is a microprocessor-controller that constantly monitors the RV battery voltage to determine if the battery requires a quick recharge, is fully charged and being used, or is fully charged and is in storage. The Charge Wizard then selects one of three charging voltages: 14.4, 13.6, or 13.2; and one of four operating modes (Boost, Normal, Storage or Desulfation) to properly re-charge or maintain the battery.
Converts: 105-130 Volt AC To 13.6 Volt DC
Continuous Output Power: 500 Watt
Ampere Rating: 30 Amp
Efficiency: 80 Percent
Length: 7-1/4 Inch
Width: 4-1/2 Inch
Height: 8-1/4 Inch
Remote On/Off Capable: No
With USB Port: No
With Volt/Watt Meter: No
With Short Circuit: No
With Reverse Battery Protection: Yes
With Thermal Protection: Yes
With Battery Cables: No
With Built-In Charger: Yes
With Fuse: No
- Reverse Battery Protection Protects Converters From Damage Resulting From Improper (Reverse) Battery Lead Connection
- Solid-State Converter/Chargers Deliver Filtered DC Power To All 12 Volt Lighting And Appliance Circuits Providing Safe And Reliable Service
- Electronic Current Limiting Automatically Reduces Output Voltage When Maximum Capacity Is Reached
- Low Line Voltage Protection Automatically Shuts Converter Down If Input Voltage Is Insufficient And Protects Appliances From Damaging Low Voltage Irregularities
- Variable Speed Intelligent Cooling Fan Automatically Monitors Converter Temperature And Activates Fan At Speed Required
- High Voltage Protection Protects Converter From Spikes Or Surge Of Voltage Over 135 Volt
- Automatic Thermal Protection Reduces Converter Output To Safe Levels When Unit Temperature Exceeds Pre-Set Limits And Protects Converter From Damage Due To Excessive Heat
